Specially designed for the European DTH markets, this Monoblock LNB provides dual satellite reception. It can be used for TV and radio reception (on 80 cm satellite dish) from two satellites... Read more.
Low Band Input Frequency Range: 10.7 ~ 11.7 GHz
Low Band Output Frequency Range: 950 ~ 1950 MHz
Low Band LO Frequency: 9.75 GHz
High Band Input Frequency Range: 11.7 ~ 12.75 GHz
High Band Output Frequency Range: 1100 ~ 2150 MHz
High Band LO Frequency: 10.6 GHz
Noise figure: 0.2 dB typ. (0.7 dB Max.)
LO Initial Accuracy: +/- 1.0 MHz Max.
LO Temperature Drift: +/- 3.0MHz Max.
Phase Noise (@ 10 kHz): - 90 dBc/Hz Max.
Conversion Gain: 50 ~ 62 dB.
Gain Ripple (Over 26MHz bandwidth): +/- 0.75 dB
Gain Variation (Over Full Band): +/- 4 dB Max.
1 dB compression point (@ Output): 0.0 dBm Min.
Mirror suppression: 40 dB Min.
Cross Polarization Isolation: 22 dB Min.
Output VSWR: 2.5:1
In-Band Spurious: - 60 dBm Max.
Power consumption: 150 mA Max. @11~20V
Operating temperature: -30°C ~ +60°C
Output Impedance: 75 Ω
Output Connector: F-Type (Female)
Weight: 270g
